Core Demand Logic of Humanoid Robots for Cemented Carbide
Transmission Precision Requirement: Components such as robot joint actuators and lead screws require micron-level positioning. Machining with cemented carbide tools ensures high-precision tooth profile/pitch tolerances for gears and threads, while the dimensional stability of cemented carbide components themselves prevents the accumulation of motion gaps.
Wear Resistance Requirement: Components like robot joints and lead screws need to withstand high-frequency reciprocating motion (it is estimated that a single robot performs over 100,000 movements per day). The wear resistance of cemented carbide is 5-10 times that of ordinary steel, significantly extending component service life.
Balance Between Lightweight and High Strength: Humanoid robots need to reduce their own weight while ensuring structural strength. Cemented carbide has a density only 1.5-2 times that of steel, but its hardness can exceed HRC60, enabling higher load capacity with a smaller volume.
Extreme Working Condition Adaptability: When robots operate in complex environments, components must withstand impacts, high temperatures, and other challenges. The thermal stability (withstanding temperatures above 800℃) and impact resistance of cemented carbide prevent component deformation or failure.
Core Application Scenarios of Cemented Carbide in Humanoid Robots
Gear Machining: Carbide Tools as the “First Line of Defense” for Transmission Precision
Carbide Hobbing Cutters: Core for Machining Large Transmission Gears
Applied Components: Robot joint reducer gears, torso transmission gears (module 2-5mm);
Technical Adaptation Advantages:
Precision Guarantee: The cutting edge precision of cemented carbide hobs can reach ±0.005mm, and the machined gear tooth profile tolerance is ≤IT6 grade, meeting the low-backlash requirements of robot transmission systems.
Efficiency Improvement: When paired with high-speed hobbing machines (cutting speed up to 300m/min), the processing efficiency under dry cutting conditions is 3-4 times that of high-speed steel hobs, adapting to mass production needs.
Wear Resistance Advantage: When machining gear steels such as 40Cr and 20CrMnTi, the service life of cemented carbide hobs is 8-10 times that of high-speed steel hobs, reducing tool change frequency and lowering machining costs.
Industrial Progress: Domestic tool manufacturers have mastered the manufacturing technology of “large outer diameter, high precision, and multi-tooth groove” cemented carbide hobs, capable of mass-supplying hobs with diameters of 50-150mm and 12-24 tooth grooves to meet the large gear machining needs of robots like Optimus.
Carbide Shaper Cutters: Precision Machining Solution for Complex Tooth Profiles
Applied Components: Harmonic reducer flexsplines, circular splines (module 0.5-1.5mm), and micro-gears for dexterous hand joints;
Core Advantages:
Complex Tooth Profile Adaptation: The shaping process can machine complex structures such as internal gears and double gears that are difficult to cover by hobbing. Cemented carbide shaper cutters have strong cutting edge rigidity, avoiding edge deformation during micro-module gear machining.
Coating Enhancement Technology: Through PVD coating treatments such as TiAlN and AlCrN, the tool surface hardness is increased to above HV3000, wear resistance is improved by 2-3 times, and tool wear per harmonic reducer gear is reduced by 50%.
Efficiency Optimization: On high-speed CNC shaping machines, the cutting speed of cemented carbide shaper cutters can reach 150m/min, twice that of high-speed steel shaper cutters. The daily output of gears per equipment increases from 50 pieces to 120 pieces.
Planetary Roller Screws: Core Structure and Machining Material of Linear Actuators
Application of Cemented Carbide in Screw Machining: Turning/Grinding Tools
Machining Process Adaptation:
Hard Turning Process: Using PCBN (Polycrystalline Cubic Boron Nitride) cemented carbide tools for finish turning of hardened steel screws with hardness 58-62HRC, achieving thread precision up to IT5 grade and surface roughness Ra≤0.4μm. The processing efficiency is 3 times that of traditional grinding processes.
Precision Grinding Process: Adopting CBN (Cubic Boron Nitride) grinding wheels, the wear loss of the grinding wheel when grinding screw thread grooves is only 1/10 that of corundum grinding wheels, reducing the processing time per piece from 20 minutes to 8 minutes.
Tool Material Selection Logic: For machining ordinary alloy steel screws, WC-Co cemented carbide tools are selected; for high-strength stainless steel and superalloy screws, TiC-Ni-Mo cemented carbide tools are used to enhance the anti-adhesion of the cutting edge.
Carbide as Screw Structure Reinforcement Material: Local Enhancement Scheme
Application Form: Cemented carbide coatings or embedded cemented carbide particles are used on the thread working surfaces of screws and roller surfaces;
Performance Improvement Effects:
Wear Resistance Enhancement: The wear resistance of coated screw surfaces is 6-8 times that of untreated steel, extending the service life of linear actuators from 10,000 hours to 50,000 hours.
Friction Coefficient Reduction: The friction coefficient of cemented carbide coatings is only 0.1-0.15, 30% lower than traditional lubrication treatments, reducing the energy consumption of actuators.
Typical Application: The planetary roller screws of Tesla Optimus linear actuators adopt WC-Co cemented carbide coatings on the roller surfaces to ensure stability under high-frequency telescopic motion.
Dexterous Hands and Joint Components: Micro Cemented Carbide Structural Parts
Dexterous Hand Gripping Mechanism: Micro Cemented Carbide Inserts
Application Scenarios: Gripping surfaces and anti-slip teeth at the fingertips of dexterous hands;
Material Selection: WC-Co cemented carbide (Co content 8-10%), balancing hardness and toughness;
Performance Advantages: Hardness exceeds HRA90, enabling easy gripping of workpieces made of different materials such as metal and plastic. The wear resistance of anti-slip teeth is 10 times that of stainless steel, avoiding gripping failure due to tooth profile wear after long-term use.
Joint Bearings and Bushings: Cemented Carbide Inserts
Application Form: Embedding cemented carbide wear-resistant layers in the inner rings of joint bearings, and manufacturing bushings through cemented carbide powder metallurgy;
Core Functions:
Reducing Friction and Wear: During joint movement, the low friction coefficient between cemented carbide and steel reduces joint heating and avoids seizing.
Enhancing Load Capacity: The compressive strength of cemented carbide exceeds 3000MPa, enabling it to withstand instantaneous impact loads of joints (up to 500N), which is twice the load capacity of ordinary bearings.
Design Case: Each of the 28 joints in Optimus’ dexterous hands is equipped with 1-2 cemented carbide embedded bushings to ensure the flexibility and durability of hand movements.
Other Auxiliary Machining Scenarios: Comprehensive Coverage of Carbide Materials Tools
Lightweight Material Machining: When processing magnesium alloy and aluminum alloy skeleton frames, PCD (Polycrystalline Diamond) cemented carbide tools are used to avoid material adhesion, achieving a surface roughness Ra≤0.8μm.
Polymer Material Machining: When cutting lightweight polymer materials such as PEEK, WC-Co cemented carbide end mills are selected for their high cutting edge sharpness, preventing material tearing and improving processing efficiency by 40%.
Housing Machining: For high-precision hole and groove machining of robot housings, cemented carbide drills and reamers are used to control hole position tolerance within ±0.01mm, meeting assembly precision requirements.
Technical Optimization Directions of Carbide Materials in Humanoid Robot Applications
Composition Optimization: Adapting to Personalized Needs of Robot Components
Low-Cobalt Design: In response to the current high cobalt prices, develop low-cobalt cemented carbide with a Co content of 4-6%. By adding alloying elements such as TiC and TaC, maintain wear resistance while reducing costs.
Fine-Grain Strengthening: Adopt nano-scale WC grains (particle size 0.2-0.5μm) to prepare fine-grain cemented carbide, increasing hardness to above HRA92 and impact resistance by 30%, suitable for impact-prone components such as micro-gears and joints.
Functional Alloys: Develop high-temperature resistant cemented carbide (adding NbC and MoC) to adapt to the high-temperature environment inside actuators (up to 150℃) and avoid material performance degradation.
Coating Technology Upgrade: Further Improving Tool and Structural Component Performance
Multi-Layer Composite Coatings: Adopt TiN/AlTiN/CrN multi-layer coatings to balance hardness and toughness, extending tool service life by 1.5 times compared to single-layer coatings.
Diamond Coatings: Deposit Diamond-Like Carbon (DLC) coatings on cemented carbide tool surfaces, reducing the friction coefficient to below 0.08 and avoiding built-up edges when machining sticky materials such as aluminum alloys and stainless steel.
Gradient Coatings: Develop gradient composition coatings for the wear resistance needs of structural components, with hardness gradually increasing from the substrate to the surface to prevent coating detachment.
Manufacturing Process Innovation: Reducing Costs and Adapting to Mass Production Needs
Powder Metallurgy Near-Net Shaping: Adopt Metal Injection Molding (MIM) technology to directly produce micro cemented carbide structural parts (such as joint bushings and dexterous hand gripping teeth), increasing material utilization rate from 60% in traditional processing to 95% and reducing production costs.
Modular Tool Design: Develop indexable cemented carbide tools with reusable tool bodies and replaceable inserts, reducing tool consumption costs.
3D Printing Technology Application: Explore cemented carbide 3D printing processes to manufacture complex-shaped tools and structural components (such as special-shaped gear machining tools and customized joint parts), shortening the R&D cycle.
Industrial Impact and Market Prospects
Promoting Role in the Humanoid Robot Industry
Performance Breakthrough: The application of cemented carbide has improved the precision of core robot components by one order of magnitude (from IT7 to IT5 grade) and extended service life by 3-5 times, providing material guarantee for robots to move from laboratories to mass production.
Cost Reduction: The efficient machining capability of cemented carbide tools has reduced the mass production cost of core components by more than 40%, driving the price of humanoid robots down from millions to 100,000 yuan and accelerating popularization.
Technological Iteration: The optimization of cemented carbide materials has forced the upgrading of robot component design, such as miniaturization and integration, promoting humanoid robots to become lighter and more flexible.
Market Demand Scale Forecast
Cemented Carbide Consumption per Robot: Taking Tesla Optimus as an example, the cemented carbide consumption per robot is approximately 13.96kg (including tool wear and structural parts). If the global mass production scale of humanoid robots reaches 1 million units by 2030, the cemented carbide market demand will reach 14,000 tons.
Segmented Market Growth: Gear machining tools, screw machining tools, and micro structural parts will become core growth areas, with an expected compound annual growth rate of over 35%.
Domestic Substitution Opportunities: Domestic cemented carbide enterprises have made breakthroughs in low-cobaltization, fine-grain alloys, coating technology, and other fields, and are expected to occupy more than 40% of the global humanoid robot cemented carbide market.
